Optional Equipment
D009/D011/D012/D013/D091/D092 1-8 SM Appendix
1.2.2 TWO-TRAY PAPER FEED UNIT
Paper Feed System: FRR
Paper Height Detection: 5 steps (100%, 70%, 30%, 10% (Near end), and Empty)
Capacity: 550 sheets x 2 trays
Paper Weight: 60 to 169 g/m
2
(16 to 45 lb.)
Paper Size: A3 SEF to A5, DLT SEF to HLT
Power Source: DC 24V, 5V (from the main frame)
Power Consumption: Less than 50 W (Max.)/ Less than 35 W (Ave,)
Dimensions (W x D x H): 580 mm x 620 mm x 260 mm (22.8" x 24.4" x 10.2")
Weight: 26 kg (57.3 lb.)
1.2.3 LCT 2000-SHEET
Paper Size: A4 LEF/LT LEF
Paper Weight: 60 g/m
2
to 169 g/m
2
, 16 lb. to 45 lb.
Tray Capacity: 2,000 sheets (80 g/m
2
, 20lb.)
Remaining Paper Detection:
5 steps (100%, 70%, 30%, 10%, Empty): Right Tray
4 steps (100%, 70%, 30%, Empty): Left Tray
Power Source: DC 24 V, 5 V (from copier/printer)
Power Consumption: 50 W (Max.)/30 W (Ave.)
Weight: 26 kg (57.3 lb.)
Size (W x D x H): 580 mm x 620 mm x 260 mm (22.8" x 24.4" x 10.2")
