Installation Requirements
D009/D011/D012/D013/D091/D092 2-2 SM
2.1.1 ENVIRONMENT
Temperature Range: 10°C to 32°C (50°F to 90°F)
Humidity Range: 15% to 80% RH
Ambient Illumination: Less than 1,500 lux (do not expose to direct sunlight.)
Ventilation: Room air should turn at least 30 m3/hr/person
Ambient Dust: Less than 0.10 mg/m3 (2.7 x 10/6 oz/yd3)
1. Avoid areas exposed to sudden temperature changes:
1) Areas directly exposed to cool air from an air conditioner.
2) Areas directly exposed to heat from a heater.
2. Do not place the machine where it will be exposed to corrosive gases.
3. Do not install the machine at any location over 2,000 m (6,500 ft.) above sea level.
4. Place the main machine on a strong and level base. Inclination on any side should
be no more than 5 mm (0.2").
5. Do not place the machine where it may be subjected to strong vibrations.
