MOTORS AND SENSORS
B408 6 SM
1.4.2 STACK HEIGHT SENSOR
1. Stack height sensor assembly [A] (
x
1)
2. Stack height sensor [B] (
x 1)
1.4.3 STAPLER TRAY PAPER SENSOR
1. Stapler tray paper sensor [A] (
x 1)
B408R121.WMF
B408R120.WMF
[A]
[B]
[A]
