Using the Debug Log
D009/D011/D012/D013/D091/D092 5-30 SM
Key to Acronyms
Acronym Meaning Acronym Meaning
ECS Engine Control Service NFA Net File Application
GPS GW Print Service PDL Printer Design Language
GSP-PM
GW Print Service – Print
Module
PTS Print Server
IMH Image Memory Handler SCS System Control Service
MCS Memory Control Service SRM
System Resource
Management
NCS Network Control Service WebDB
Web Document Box
(Document Server)
The machine is now set to record the debugging information automatically on the HDD (the
target selected with SP5-857-002) for the events that you selected SP5-858and the
memory modules selected with SP5-859.
Please keep the following important points in mind when you are doing this setting:
 Note that the number entries for Keys 1 to 5 are the same for the Copy, Printer,
Scanner, and Web memory modules.
 The initial settings are all zero.
 These settings remain in effect until you change them. Be sure to check all the settings,
especially the settings for Keys 6 to 10. To switch off a key setting, enter a zero for that
key.
 You can select any number of keys from 1 to 10 (or all) by entering the corresponding
4-digit numbers from the table.
 You cannot mix settings for the groups (COPY, PRINTER, etc.) for 006to010. For
example, if you want to create a PRINTER debug log you must select the settings from
the 9 available selections for the "PRINTER" column only.
 One area of the disk is reserved to store the debug log. The size of this area is limited
to 4 MB.
