Output Check
D009/D011/D012/D013/D091/D092 4-256 SM Appendix
4.10.3 2000/3000-SHEET (BOOKLET) FINISHER
6145 Display Description
6145 1 Entrance Motor Finisher Entrance Motor
6145 2 Upper Feed Motor Upper Transport Motor
6145 3 Lower Feed Motor Lower Transport Motor
6145 4 Exit Motor Upper/Proof Tray Exit Motor
6145 5 Knock Roller Motor Clamp Roller Retraction Motor
6145 6 Shift Motor Shift Roller Motor
6145 7
Exit Guide Plate
Open/Close Motor
Exit Guide Plate Motor
6145 8 Tray Lift Motor Upper Tray Lift Motor
6145 9
Oscillating Back
Roller Motor
Stacking Sponge Roller Motor
6145 10 Jogger Motor Jogger Fence Motor
6145 11
Stack Feed-out
Motor
Feed Out Belt Motor
6145 12
Staple Moving
Motor
Corner Stapler Movement Motor
6145 13 Staple Skew Motor Corner Stapler Rotation Motor
6145 14 Staple Motor Corner Stapler EH530
