Drive Area
SM 4-83 D009/D011/D012/D013/D091/D092
Replacement
&
Adjustment
4.15.2 DEVELOPMENT PADDLE MOTOR
1. Rear cover ( p.4-4)
2. Development paddle motor [A] (
x 4, x 1)
4.15.3 TRANSFER/DEVELOPMENT MOTOR
1. Rear cover ( p.4-4)
2. Transfer/development motor [A] (
x 4, x 1)
