190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 7-2
7.1.1 Status LED
The GEA 24 has an LED on its outer case that indicates its current status. See Section 31.1.1
for details.
7.2 Equipment Available
7.2.1 Required Equipment
NOTE
Refer to Section 32.2.5 for information regarding swapping GEA 24 and GEA 24B units.
7.2.2 Additional Equipment Required
Table 7-2 lists the content of the GEA 24 Connector Kit, which is required to install the unit. Use of the
CAN Termination Kit is detailed in Section 2.3.1.3.3
.
Table 7-1 GEA 24 Part Numbers
Model
Assembly Part
Number
Unit Only Part
Number
GEA 24 010-01042-00 011-02848-00
GEA 24B 010-02770-00 011-05991-00
Table 7-2 Contents of GEA 24 Connector Kit (011-02886-00)
Item Garmin P/N Quantity
Backshell w/Hdw, Jackscrew, 9/15 Pin 011-01855-00 1
Backshell w/Hdw, Jackscrew, 25/44 Pin 011-01855-02 1
Backshell w/Hdw, Jackscrew, 37/62 Pin 011-01855-03 1
Backshell w/Hdw, Jackscrew, 50/78 Pin 011-01855-04 1
CAN termination kit 011-02887-00 1
Conn, Plug,D-Sub, Crimp Pin, Commercial, 25 CKT 330-00624-25 1
Conn, Rcpt, D-Sub, Crimp Socket, Commercial, 09 CKT 330-00625-09 1
Conn, Rcpt, D-Sub, Crimp Socket, Commercial, 37 CKT 330-00625-37 1
Conn, Rcpt, D-Sub, Crimp Socket, Commercial, 50 CKT 330-00625-50 1
Contact, Socket, Military Crimp, Size 20 336-00022-02 100
Contact ,Pin, Military Crimp, Size 20 336-00024-00 30
