190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 29-2
29.2 GEA™ 24 Engine Interface Module - Jabiru Sensor Drawings
Figure 29-2 GEA 24 - Jabiru Sensor Wiring Examples, Page 1 of 2
GEA 24
J243
RPM 1 8
JABIRU
S
OIL TEMP LO
OIL TEMP HI
32
33
OIL TEMP SENSOR
VDO P/N 320021
S
OIL PRESS LO
OIL PRESS HI
16
17
GROUND
OUTPUT
OIL PRESS SENSOR
VDO P/N 360001 OR
S
MANIFOLD PRESS
MANIFOLD PRESS GND
13
12
FUEL XDCR GND_1
FUEL FLOW
20
23
FUEL FLOW TRANSDUCER
OUT LO/GND
OUT HI
FUEL XDCR +12V_1 24 EXCITATION INPUT
S
FUEL PRESS GND
FUEL PRESS
1
2
EI FT-60 (RED CUBE) OR
FLOSCAN 201B-6
FUEL PRESS SENSOR
S
MANIFOLD PRESS SENSOR
S
GROUND (PIN A)
OUTPUT (PIN C)
VOLTAGE IN (PIN B)
FUEL PRESS XDCR +5V 4
GARMIN GPT 15G OR
KAVLICO P4055-5020-2
GARMIN GPT 30A,
KAVLICO P4055-30A-E4A,
OR KAVLICO P500-30A-E4A
RED
WHT
BLK
RED
GRN
BLK
BATTERY CONTACTOR
BATTERY POSITIVE
36
37SHUNT 1 HI
SHUNT 1 LO
AMPS 1, UMA 1C4
BLU
WHTWHT
BLU
S
1A
1A
/ ALTERNATOR B LEAD
/ POWER DISTRIBUTION BUS
.0005 OHM
SEE NOTE 11
SEE NOTE 6
ELO P/N 206.252.035
SEE NOTE 12
MAN. PRESS XDCR +5V 15
GROUND (PIN A)
OUTPUT (PIN C)
VOLTAGE IN (PIN B)RED
GRN
BLK
ALTERNATOR PICK-OFF

Garmin G3X Specifications

General

Display Type	LCD
Touchscreen	Yes
Power Input	10-32 VDC
Connectivity	Bluetooth, Wi-Fi (optional)
Interfaces	RS-232
GPS	Internal GPS/WAAS receiver
AHRS	Integrated AHRS
Air Data Computer	Integrated Air Data Computer
Autopilot Compatibility	Compatible with Garmin autopilots
Operating Temperature	-20°C to +55°C
Sunlight Readability	Sunlight readable display
Screen Size	10.6 inches
