190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 4-1
4 GAD 29/29B/29C/29D (ARINC 429 ADAPTER) INSTALLATION
This section contains general information as well as installation information for the GAD 29. Use this
section to mount the GAD 29 unit.
NOTE
A GAD 29 cannot be installed in a system that also includes a GSU 73. For
ARINC 429 I/O, use the appropriate pins on the GSU 73 instead.
NOTE
All information for the GAD 29 is applicable to the GAD 29B/29C/29D unless explicitly
noted.
NOTE
The GAD 29 was a prior version of the GAD 29C, all form, fit, and functions are identical
for the two models.
NOTE
The GAD 29B was a prior version of the GAD 29D, all form, fit, and functions are
identical for the two models.
Figure 4-1 GAD 29 Unit View
J291J291
J292J292
