190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 16-17
16.5.3 Unit Mounting
For final installation and assembly, refer to the outline and installation drawings Figure 16-8.1
through
Figure 16-14.1
.
WARNING
Unless otherwise specified, tighten all threaded fasteners in accordance with FAA advisory
circular AC 43-13-1B section 7.40, including adjustment for friction drag torque.
16.6 Unit Wiring
Refer to the Section 24-1.7 interconnect drawing for connecting GSA 28 wiring.
16.7 Outline and Installation Drawings
Refer to the following figures for GSA 28 installation guidance.
