190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 23-8
These active-low discrete inputs conform to the following specification:
Low: Vin < 3.5 VDC, or Rin < 375 Ω (input active)
High: Vin > 8 VDC, or Rin> 100k Ω (input inactive)
23.1.10 Motor Disconnect Input
Motor Disconnect is an active low discrete input, that when active, interrupts trim and flap movement.
Connecting this input to a switch is not required, the unit will operate normally when the switch is either
inactive or the input is not used.
NOTE
When Motor Disconnect is active, all trim will be reflected as inhibited in the system status
menu.
The Motor Disconnect input is an active-low discrete input that conforms to the following specification:
Low: Vin < 3.5 VDC, or Rin < 375 Ω (input active, motor movement inhibited)
High: Vin >8 VDC, or Rin > 100k Ω (input inactive, motor movement allowed)
Pin Name Connector Pin I/O
LIGHT 2 SWITCH J271 34 In
LIGHT 1 SWITCH J271 35 In
ALTERNATING FLASH ON J271 36 In
Pin Name Connector Pin I/O
MOTOR DISCONNECT J271 16 In
