190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page H-2
H.1 Recommended Test Equipment
The following test equipment is recommended to conduct and complete all post installation checkout
procedures in this section: (All test equipment should have current calibration records)
• Pitot/static ramp tester
• Digital Multi-Meter (DMM)
• Ground power unit capable of supplying 14/28 Vdc power to the aircraft systems and avionics
• Outdoor line-of-sight to GPS satellite signals or GPS indoor repeater
• Digital Level or equivalent

Garmin G3X Specifications

General

Display Type	LCD
Touchscreen	Yes
Power Input	10-32 VDC
Connectivity	Bluetooth, Wi-Fi (optional)
Interfaces	RS-232
GPS	Internal GPS/WAAS receiver
AHRS	Integrated AHRS
Air Data Computer	Integrated Air Data Computer
Autopilot Compatibility	Compatible with Garmin autopilots
Operating Temperature	-20°C to +55°C
Sunlight Readability	Sunlight readable display
Screen Size	10.6 inches
