Garmin G3X User Manual

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page E-4
E.2 General Specifications
See Section 2.2 for power/current specifications, and Section 2.4.1 for dimension/weight specifications.
E.3 Installation Information
E.3.1 Required Equipment
Each of the following accessories is provided with the GDU 37X unit (010-00667-15). The connector kit is
required to install the unit (Figure E-3
). The GDU 37X Nut Plate (Figure E-3) is included in the
installation kit for use when it is not possible to tap the instrument panel for 6-32 screw threads.
The contents of the GDU 37X Connector Kit are listed in Table E-1. One kit is required for each GDU 37X
installed.
Table E-1 Contents of GDU 37X Connector Kit (011-01921-00)*
Item Garmin P/N Quantity
Sub-Assy, bkshl w/Hdw, Jackscrew 011-01855-04 1
Conn, Rcpt, D-Sub, Crimp Socket 330-00625-50 1
Contact, Sckt, D-Sub, Crimp, Size 20 336-00094-00 20

Garmin G3X Specifications

General

Display Type	LCD
Touchscreen	Yes
Power Input	10-32 VDC
Connectivity	Bluetooth, Wi-Fi (optional)
Interfaces	RS-232
GPS	Internal GPS/WAAS receiver
AHRS	Integrated AHRS
Air Data Computer	Integrated Air Data Computer
Autopilot Compatibility	Compatible with Garmin autopilots
Operating Temperature	-20°C to +55°C
Sunlight Readability	Sunlight readable display
Screen Size	10.6 inches
