190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 6-1
6 GDU™ 4XX DISPLAY INSTALLATION
NOTE
References to the GDU 4XX throughout this manual apply equally to the GDU 45X,
GDU 46X, and GDU 47X except where specifically noted.
This section contains general information as well as installation information for the GDU 4XX units. Use
this section to mount the GDU 45X/46X/470 unit(s).
Figure 6-1 GDU 45X Unit View
Figure 6-2 GDU 46X Unit View
