190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 30-226
30.4.32.31 Engine Power
Estimated engine power can be calculated for Lycoming and Continental engines, using inputs from RPM,
manifold pressure, and fuel flow sensors (all three are required for engine power calculation).
On the Engine Power Configuration page, select the appropriate engine type (Lycoming or Continental,
turbocharged or normally-aspirated). Then enter the engine's maximum rated power and RPM (for
example, 180 horsepower at 2750 RPM).
For a turbocharged engine, enter the manifold pressure for maximum rated power. Configuring maximum
manifold pressure is not required for a normally-aspirated engine, as it is assumed to produce maximum
power at sea level pressure.
To display engine power data or related status information from a FADEC engine, select "FADEC" for the
engine type. Not all FADEC types provide engine power information; some other FADEC types provide
general power status (for example, an Economy mode indication) but not a percentage.
