190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 23-50
23.10.2.1 Unit ID
Install a jumper connecting pin 3 to pin 6 to configure unit as Magnetometer #2.
23.10.2.2 CAN Bus
The CAN Bus conforms to the BOSCH standard for Controller Area Network 2.0-B, and complies with
ISO 11898. Refer to Section 2.3.1.3
for details on wiring the CAN bus.
Pin Name Connector Pin I/O
UNIT ID J111 3 IN
SIGNAL GROUND J111 6 --
Pin Name Connector Pin I/O
CAN BUS HI J111 1 I/O
CAN BUS LO J111 2 I/O
