Garmin G3X User Manual

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 4-4
4.6 Outline and Installation Drawings
Figure 4-2 GAD 29 Outline Drawing
6.100
154.94
1.479 37.57
.100 2.54
.040 1.02
TYPICAL THICKNESS
BENEATH FASTENER HEAD
2X 2.352
59.74
2X 5.600
142.24
2X .250
6.35
2X .369
9.37
5.539
140.68
WITH CAN TERMINATOR
5.095[129.41]
WITHOUT CAN TERMINATOR
5.095
129.41
2.950 74.93
CENTER OF GRAVITY
3.090 78.49
3.235 82.17
.675
17.15
CENTER OF GRAVITY
2.350 59.69
CENTER OF GRAVITY
NOTES:
DIMENSIONS IN INCHES [mm]. METRIC VALUES ARE FOR REFERENCE ONLY.
1.
DIMENSIONS ARE NOMINAL AND TOLERANCES ARE NOT IMPLIED UNLESS SPEIFICALLY STATED.
2.

Garmin G3X Specifications

General

Display Type	LCD
Touchscreen	Yes
Power Input	10-32 VDC
Connectivity	Bluetooth, Wi-Fi (optional)
Interfaces	RS-232
GPS	Internal GPS/WAAS receiver
AHRS	Integrated AHRS
Air Data Computer	Integrated Air Data Computer
Autopilot Compatibility	Compatible with Garmin autopilots
Operating Temperature	-20°C to +55°C
Sunlight Readability	Sunlight readable display
Screen Size	10.6 inches
