190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 4-3
4.3 General Specifications
See Section 2.2 for power/current specifications, and Section 2.4.1 for dimension/weight specifications.
4.4 Mounting Requirements
The GAD 29 will mount remotely. The GAD 29 will be secured to the airframe using four screws supplied
by the installer. Refer to Section 4.6
for outline and installation drawings.
4.5 Unit Installation
Fabrication of a wiring harness is required. Sound mechanical and electrical methods and practices are
recommended for installation of the GAD 29. Refer to Section 2.3
for wiring considerations, and to
Section 23.2
for pinouts.
1. Mount the unit to a suitable mounting location using (4) #10-32 pan or hex head screws.
2. Assemble the connector backshells and wiring harness.
3. Connect CAN terminator to unit if required (Section 2.3.1.3.3
).
4. Connect backshell connectors.
