Garmin G3X User Manual

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 29-4
29.3 GSU 73 - Jabiru Sensor Drawings
Figure 29-3 GSU 73 - Jabiru Sensor Wiring Examples, Page 1 of 2
GSU 73
J732
RPM 17
JABIRU
S
OIL TEMP LO
OIL TEMP HI
14
34
OIL TEMP SENSOR
VDO P/N 320021
S
POS 3/GP 3/FUEL FLOAT 3 LO
POS 3/GP 3/FUEL FLOAT 3 HI
7
27
GROUND
OUTPUT
OIL PRESS SENSOR
VDO P/N 360001 OR
S
MANIFOLD PRESS HI
MANIFOLD PRESS LO
65
6
XDCR PWR OUT LO (GND)
FUEL FLOW 1
56
19
FUEL FLOW TRANSDUCER
OUT LO/GND
OUT HI
+12V TRANSDUCER POWER 55 EXCITATION INPUT
S
FUEL PRESS LO
FUEL PRESS HI
45
26
EI FT-60 (RED CUBE) OR
FLOSCAN 201B-6
FUEL PRESS SENSOR
S
GROUND
OUTPUT
SUPPLY VOLTAGE
MANIFOLD PRESS SENSOR
S
GROUND
OUTPUT
SUPPLY VOLTAGE
+5V TRANSDUCER POWER 75
57
GARMIN GPT 15G OR
KAVLICO P4055-5020-2
GARMIN GPT 30A OR
KAVLICO P4055-30A-E4A
XDCR PWR OUT LO (GND)
RED
WHT
BLK
B
C
A
B
C
A
BATTERY CONTACTOR
BATTERY POSITIVE
50
70SHUNT 1 HI
SHUNT 1 LO
AMPS 1, UMA 1C4
BLU
WHTWHT
BLU
S
1A
1A
/ ALTERNATOR B LEAD
/ POWER DISTRIBUTION BUS
.0005 OHM
SEE NOTE 11
SEE NOTE 6
ELO P/N 206.252.035
SEE NOTE 12
ALTERNATOR PICK-OFF

Garmin G3X Specifications

General

Display Type	LCD
Touchscreen	Yes
Power Input	10-32 VDC
Connectivity	Bluetooth, Wi-Fi (optional)
Interfaces	RS-232
GPS	Internal GPS/WAAS receiver
AHRS	Integrated AHRS
Air Data Computer	Integrated Air Data Computer
Autopilot Compatibility	Compatible with Garmin autopilots
Operating Temperature	-20°C to +55°C
Sunlight Readability	Sunlight readable display
Screen Size	10.6 inches
