190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 6-4
6.3 Installation Information
6.3.1 Required Equipment
A installation kit (Table 6-1, Table 6-2, Table 6-3) is required to install the unit, one kit is required for each
GDU 4XX installed. The GDU 4XX Nut Plate (Figure 6-6
GDU 45X, Figure 6-9 GDU 46X, Figure 6-12
GDU 470) is included in the installation kit for use when it is not possible to tap the instrument panel for
6-32 screw threads. The installation kits are not included with the GDU 4XX.
A separate drilling guide is included to aid the installation of a GDU 470 in a panel that formerly contained
a GDU 37X display.
Table 6-1 Contents of GDU 45X Installation Kit (010-12150-01)*
Item Garmin P/N Quantity
GDU 45X Connector Kit* 011-01921-10 1
Nut Plate Kit 115-01725-00 1
Machine Screw for Panel Mounting, 0.550”, Black 211-00169-01 4
*Contents of the connector kit are listed in Table 6-4
Table 6-2 Contents of GDU 46X Installation Kit (010-12150-00)
Item Garmin P/N Quantity
GDU 46X Connector Kit* 011-01921-10 1
Nut Plate Kit 115-01725-01 1
Machine Screw for Panel Mounting, 0.550”, Black 211-00169-01 4
*Contents of the connector kit are listed in Table 6-4
Table 6-3 Contents of GDU 470 Installation Kit (010-12150-02)*
Item Garmin P/N Quantity
GDU 4XX Connector Kit* 011-01921-10 1
Nut Plate Kit 115-01725-03 1
GDU 47X Drill Guide 115-01725-04 1
Machine Screw for Panel Mounting, 0.550”, Black 211-00169-01 4
*Contents of the connector kit are listed in Table 6-4
Table 6-4 Contents of GDU 4XX Connector Kit (011-01921-10)
Item Garmin P/N Quantity
Sub-Assy, bkshl w/Hdw, Jackscrew 011-01855-04 1
Conn, Rcpt, D-Sub, Crimp Socket 330-00625-50 1
Contact, Sckt, D-Sub, Crimp, Size 20 336-00022-02 30
To Next Page
