190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual

Rev. AV Page 20-31

20.8 Outline and Installation Drawings

Figure 20-32 GA 35 Installation Drawing

CAUTION

GA 35 antennas with serial numbers below 110000 required screws with 80°

countersink angle and most aviation fasteners (AN509) are NOT compatible.

Serial numbers 110000 and higher, AN509 hardware is compatible.
