190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page D-9
D.12.2 Performance Information
The GSU 25 is capable of maneuvers through a range of 360° in bank and pitch. The rotation rate
capability is ±500° per second.
Pitch/roll accuracy is +/- 2 degrees, heading accuracy is 3 degrees in straight and level flight.
Pitch/roll accuracy is 3.5 degrees and heading accuracy is +/-5 degrees under normal dynamic
maneuvering (bank < 35°, pitch <15°).
Due to unsuitability of the magnetic fields near the Earth’s poles, operational accuracy is unknown in the
following regions:
1. North of 72° North latitude at all longitudes
2. South of 70° South latitude at all longitudes
3. North of 65° North latitude between longitude 75° W and 120° W (Northern Canada)
4. North of 70° North latitude between longitude 70° W and 128° W (Northern Canada)
5. North of 70° North latitude between longitude 85° E and 114° E (Northern Russia)
6. South of 55° South latitude between longitude 120° E and 165° E (Region South of Australia and
New Zealand)

Garmin G3X Specifications

General

Display Type	LCD
Touchscreen	Yes
Power Input	10-32 VDC
Connectivity	Bluetooth, Wi-Fi (optional)
Interfaces	RS-232
GPS	Internal GPS/WAAS receiver
AHRS	Integrated AHRS
Air Data Computer	Integrated Air Data Computer
Autopilot Compatibility	Compatible with Garmin autopilots
Operating Temperature	-20°C to +55°C
Sunlight Readability	Sunlight readable display
Screen Size	10.6 inches
