190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page D-12
D.15 GTR 20/200
D.15.1 Environmental Specifications
Table D-16 lists general environmental specifications.
D.15.2 License Requirements
The Telecommunications Act of 1996, effective February 8, 1996, provides the FCC discretion to
eliminate radio station license requirements for aircraft and ships. GTR 20/200 installations must comply
with current transmitter licensing requirements. In the US, to find out the specific details on whether a
particular installation is exempt from licensing, please visit the FCC website
www.fcc.gov/wireless/bureau-divisions/mobility-division/aviation-radio-services
. If an aircraft license is
required, make application for a license on FCC form 404, Application for Aircraft Radio Station License.
The FCC also has a fax-on-demand service to provide forms by fax. Outside the US, contact the
responsible telecommunication authority. The GTR 20/200 owner accepts all responsibility for obtaining
the proper licensing before using the transceiver. The maximum transmitting power, modulation
identification, and frequency band information may be required for licensing and are detailed in
Section 19.3.1
.
D.15.3 Aircraft Radio
An aircraft radio station license is not required when operating in U.S. airspace, but may be required when
operating internationally.
D.15.4 Certification
The GTR 20/200 does not have TSO authorization.
D.15.5 FCC Grant of Equipment Authorization
D.15.6 Industry Canada Compliance
The GTR 20/200 device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired operation of the device.
Table D-16 GTR 20/200 Environmental Specifications
Characteristic Specification
Operating Temperature Range -20°C to +55°C
Humidity 95% non-condensing
Altitude Range -1,500 ft to 55,000 ft
Table D-17 FCC Grant of Equipment Authorization
Model FCC ID IC ID
GTR 20/200 IPH-0211501 1792A-0211501
