190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 8-1
8 GHA 15 HEIGHT ADVISOR INSTALLATION
This section contains information for the GHA 15 Height Advisor. Use this section to install the GHA 15.
8.1 Equipment Description
The GHA 15 Height Advisor uses radar to provide above ground level (AGL) sensor readings up to a
maximum of 500 ft and is designed for aircraft flying up to 25,000 ft. The GHA 15 output provides AGL
data and configurable audio callouts for reference only. The GHA 15 does not satisfy aircraft radar
altimeter requirements.
The GHA 15 features low-power FMCW operation, operation from ground to 500 ft AGL Max., accuracy
of +/- 1.5 ft (3 – 100 ft AGL), +/- 2% (>100 – 500 ft AGL), CAN interface for convenient unit
configuration, calibration and software updates, in addition to a standard USB high speed interface for
diagnostics purposes.
NOTE
It is recommended to install a USB harness to provision the installation for access to
diagnostic information, see Section 23.5.4
for more information.
8.2 Equipment Available
8.2.1 Accessories
Table 8-1 GHA 15 Part Numbers
Model Assembly Part Number Unit Only Part Number
GHA 15 010-02463-00 011-05259-50
GHA 15*, Standard 010-02942-00 011-05259-50
*Includes connector kit (011-05278-00) and install kit (011-06097-00)
Table 8-2 Available Accessories
Item Garmin P/N Quantity
GHA 15 USB-B Pigtail* 011-01782-00 1
GHA 15 Connector Kit 011-05278-00 1
GHA 15 Install Kit 011-06097-00 1
*USB connection is optional for diagnostics and troubleshooting while aircraft is on ground. Contact
Garmin for additional guidance.
Table 8-3 Contents of GHA 15 Connector Kit (011-05278-00)
Item Garmin P/N Quantity
Conn,Circ, Plug, D38999/26, Ins 13- 35, Alum,Crimp, Key A 330-01288-01 1
Conn Seal Plug, MS27488-22 330-90013-01 20
Backshell, Circular, Strain Relief, AS85049/126, RA, Size 13 330-90049-03 1
