190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 14-2
14.2 General Specifications
See Section 2.2 for power/current specifications, and Section 2.4.1 for dimension/weight specifications.
14.3 Equipment Available
Table 14-1 GMU 22 Part Numbers
Model
Assembly Part
Number
Unit Only Part
Number
Installation Rack
GMU 22 010-01196-00 011-03269-00 No
Table 14-2 GMU 22 Accessories
Item Garmin P/N Quantity
GMU 22, Connector Kit 011-00871-10 1
GMU 22 Universal Mount* 011-01779-01 1 (optional)
Installation Rack, GMU 22 115-00481-10 1
*Refer to AHRS Magnetometer Installation Considerations (190-01051-00) from www.garmin.com
Table 14-3 Contents of GMU 22 Connector Kit (011-00871-10)
Item Garmin P/N Quantity
Modified Install Rack 115-00481-10 1
Screw, 6-32x .250, Pan Head Phillips, Brass, w/Nylon 211-60037-08 3
Circular Connector, Female, 9 Ckt 330-00360-00 1
Circular non-Magnetic Backshell 330-90005-01 1
Socket Contact Mil Crp, Size 20 336-00022-00 10
