190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 1-3
1.3.2 GPS/XM Antenna(s)
A Garmin or non-Garmin GPS antenna is required for a G3X installation. A Garmin or non-Garmin XM
antenna is required for G3X installations using SiriusXM® weather. See Section 20
for required materials
for antenna installation including mounting brackets, doubler plates, rivets, hardware, cables, connectors,
and sealant.
GSA 28 Servo Actuator
011-02950-00, Conn Kit (Table 16-6)
011-02950-01, 90° Conn Kit (Table 16-
7)
N
GSU 25 ADAHRS K10-00181-00, Conn Kit (Table 17-2 ) Y
GSU 73 ADAHRS/EIS NA Y
GTP 59 Temperature Probe 011-00978-00 (Table 18-2) Y
GTR 20 011-03241-00 (Table 19-3) Y
Garmin GPS and/or XM Antennas NA N
Table 1-5 Contents of GDL 39R Connector Kit (010-11825-20)
Item Part Number Quantity
Backshell w/Hdw, Jackscrew, 9/15 pin 011-01855-00 1
Conn, Receptacle, d-Sub, Crimp Socket, Commercial,
9 CKT
330-00625-09
1
Contact, Sckt, Mil Crimp, size 20, 20-24 AWG 336-00022-02 9
Table 1-6 Contents of GDL 5XR Connector Kit (010-12498-60)
Item Part Number Quantity
Backshell w/Hdw, Jackscrew, 15/26 pin 011-01855-01 1
Conn, Receptacle, d-Sub, Crimp Socket, Commercial,
15 CKT
330-00625-15
1
Contact, Sckt, Mil Crimp, size 20, 20-24 AWG 336-00022-02 16
Table 1-4 LRU Connector/Installation Kits
LRU
Connector/Installation
Kit Part Number
Installation Kit
Included with LRU?
