COPYRIGHT
©
2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 1 GENERAL DESCRIPTION
1-7 P
2. Image Formation
2.1 Outline
The machine uses an indirect electrophotographic method to form images, and is con-
structed as follows:
F01-201-01 Construction of the Machine
Copyboard glass
Scanning lamp
Primary charging assembly
Pre-exposure LED
Potential sensor
Dust-collecting roller
Pickup
(manual feed tray)
Pickup (deck/cassette)
Transfer assembly
Separation
charging assembly
Cleaning assembly
Fixing assembly
Separation
claw
Pre-transfer
charging assembly
