Canon iR5000 - Adjusting the Height of the Charging Wire

COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 4 IMAGE FORMATION SYSTEM
4-71 P
7.8.5 Adjusting the Height of the Charging Wire
T-04-708-01
REF.
The height (position) of the pri-
mary charging wire and the
transfer charging wire may be
adjusted by turning the screw
found at the back of the charg-
ing assembly; a single turn
changes the position of the
charging wire by about 0.7 mm.
Charging assembly Height of charging wire Tolerance
Primary
Pre-transfer
±2mm
Transfer
Separation
A
B
C
D
7.5
+1.5
- 0 mm
9.5±0.5mm
14.9±0.5mm
±1mm
±2mm
7.5
+1.5
- 0 mm
10.06±0.3 mm
No height adjusting
mechanism
16.0±0.5mm
