CHAPTER 1 MAINTENANCE AND INSPECTION
1-2 T
1.3 Printer Unit
As of June 2000
No. Part name Part No. Q’ty Life Remarks
1 Primary, pre-transfer, transfer, FB4-3687 AR 500,000*
separation charging wire
2 Primary grid wire FY1-0883 AR 500,000
3 Primary charging wire FF5-6883 2 500,000 Strengthened polish
cleaner 1 type (blue)
4 Primary charging wire FF2-6884 2 500,000 Strengthened polish
cleaner 2 type (blue)
5 Transfer charging wire FF5-6883 1 500,000 Strengthened polish
cleaner 1 type (blue)
6 Transfer charging wire FF5-6884 1 500,000 Strengthened polish
cleaner 2 type (blue)
7 Separation charging wire FF5-3090 1 500,000
cleaner
8 Pre-transfer charging wire FF5-3090 1 500,000
cleaner
9 Main thermistor FH7-7529 1 500,000
10 Sub thermistor FG5-8812 1 500,000
11 Ozone filter FB5-5570 1 500,000
12 Thermal switch FH7-7154 1 1,000,000
*Do not use the old type (gold plated). After replacement of the charge wire, be sure to
execute wire cleaning in service mode. (COPIER>FUNCTION>CLEANING>WIRE-
CLN)
T01-103-01
Memo
The indicated life of each part is for reference only, and is subject to the site
environment and the conditions of use.
