CHAPTER 3 STANDARDS AND ADJUSTMENTS
3-8 T
3. Image Formation System
3.1 Routing the Grid Wire of the Primary Charging Assembly
See the Printer Manual: Chap. 4>7.8 “Charging Wire”
3.2 Routing the Charging Wire of Charging Assemblies
See the Printer Unit: Chap. 4>7.8 “Charging Wire”
3.3 Mounting the Drum Cleaning Blade
See the Printer Manual: Chap. 4>7.11 “Drum Cleaner”
3.4 Mounting the Developing Blade
See the Printer Manual: Chap. 4>7.8 “Developing Assembly”
3.5 Replacing the Potential Sensor/Potential Control PCB
See the Printer Unit: Chap. 4>7.4 “Potential Sensor Assembly”
1. The potential sensor and the potential control PCB are adjusted as a
single unit; be sure to replace both at the same time.
2. If you have replaced the sensor and the PCB, be sure to execute offset
adjustment of the sensor.
