Canon iR5000 - Detecting the Waste Toner

COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 4 IMAGE FORMATION SYSTEM
4-44 P
5.2 Detecting the Waste Toner
The system used to detect waste toner (full condition) is constructed as follows:
F04-502-01
DC controller PCB
Waste toner bottle
(front)
J108A
J107
M1_ON
M1_LCK
0V
WT-RCK
5V
0V
1
10
9
···
11
12
1
···
17
18
M1
Main motor
To MSW1
Waste toner feedscrew
lock detection
(MSW1)
