5. Troubleshooting Feeding Faults
5.1 Paper Jams
Jams occurring in the machine may be grouped into the following by location:
1. Pickup assembly
2. Separation/feeding assembly
3. Fixing/delivery assembly
4. Drum cleaning assembly
5. Duplex reversing assembly
6. Feeding assembly
The troubleshooting procedures that follow are organized according to location; to find
out the location and the nature of a jam, use service mode (COPIER>DISPLAY>JAM).
F04-501-01
[2]
[3] [4]
[5] [6]
[1]
