Canon iR5000 - Controlling the Registration Clutch; Control System; Outline

COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 5 PICK-UP/FEEDING SYSTEM
5-25 P
3. Controlling the Registration Clutch
3.1 Outline
The registration clutch is controlled so that print paper and the image on the drum match
at a specific point, and the timing at which it is turned on may be adjusted in service mode
(ADJUST>FEED-ADJ>REGIST).
3.2 Control System
F05-302-01
CL2
J106-A6
Registration rollers
Main motor
Registration drive signal
(RGCD*)
DC controller
PCB
M2
