COPYRIGHT
©
2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 4 IMAGE FORMATION SYSTEM
4-37 P
4.2 Controlling the Drive to the Hopper/Developing Assembly
The system used to control the drive of the developing assembly is constructed as follows:
F04-402-01
CL1
Developing assembly clutch
M1
DC controller PCB
M10ON*[1]
24V
J103B
1
5
6
7
8
M9ON* [2]
24V
M1_ON
0V
M1_LCK
5V
J108A
1
9
10
11
12
DEVCD* [3]
24V
J108B
1
2
M10
M9
Hopper stirring motor
Hopper supply motor
