F. List of Special Tools
The following special tools will be needed in addition to the standard tools set:
No.
1
2
3
4
5
Name
Digital
multimeter
Door switch
Mirror
positioning tool
(front, rear)
NA-3 Test Sheet
Potential sensor
electrode
Toll No.
FY9-2002
TKN-0093
FY9-3009
FY9-9196
FY9-3012
Shape Rank
A
A
B
A
B
Remarks
Used when making
electrical checks.
Used when positioning
the No. 1/No. 2 mirror.
Used when adjusting/
checking images.
Used to make zero-level
checks on potential
sensors.
