Canon iR5000 User Manual

COPYRIGHT © 2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 4 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
4-63 T
M
M
6.3.1 Reader Unit
Symbol Name Notation Function
Motor M3 Scanner motor
6.3.2 Printer Unit
Symbol Name Notation Function
Motor M1 Drum motor
M2 Main motor
M4 Left deck lifter motor
M5 Right deck lifter motor
M6 Primary charging wire cleaning motor
M7 Pre-transfer charging wire cleaning motor
M8 Transfer/separation charging wire cleaning motor
M9 Hopper stirring motor
M10 Hopper supply motor
M11 Right deck pickup motor
M12 Cassette 3/4 pickup motor
M13 Delivery motor
M14 Reversal motor
M15 Laser scanner motor
M16 Duplex horizontal registration motor
M17 Pre-registration motor
M18 Duplex feeding right motor
M19 Fixing motor
M20 Cassette 3 lifter motor
M21 Cassette 4 lifter motor
M24 Left deck pickup motor
M25 Vertical path duplex feeding motor
M26 Vertical path upper motor
M27 Vertical path lower motor
M29 Duplex feeding left motor
