3.15 The print has a displaced leading edge
(appreciably large margin)
3.16 The print has a displaced leading edge (large margin)
3.17 The print has a displaced leading edge (no margin)
Placement of originals
1) Is the original placed correctly?
NO: Place the original correctly.
Pickup assembly
2) Make prints using the following source of paper. Is the displaced lead-
ing edge different?
1. Let/right front deck
2. Cassettes
3. Side paper deck
4. Duplex feeding assembly (double-sided print)
YES: Check the source of paper in question for the following:
1. Life of each roller
2. Paper lint on each roller
3. Dirt on the paper path
Registration clutch, Registration roller
3) Make adjustments in service mode: COPIER>ADJUST>Feed-
ADJ>REGIST. Is the problem corrected?
YES: End.
NO:
1. Check the registration roller for deformation/wear.
2. Check the registration roller drive system.
