COPYRIGHT
©
2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 4 IMAGE FORMATION SYSTEM
4-36 P
4. Hopper/Developing Assembly
4.1 Outline
The following component parts are associated with the developing assembly:
F04-401-01
Feed screw
Developing assembly toner sensor (TS1)
M1
CL1
Developing assembly clutch
Developing cylinder
Toner feed screw
Toner feed screw
M10
Angled feed screw
Stirring rod
Toner sensor (TS2)
M9
Hopper stirring motor
Hopper supply motor
Main motor
Toner supply
