COPYRIGHT
©
2000 CANON INC. 2000 2000 2000 2000 CANON iR5000/iR6000 REV.0 JULY 2000
CHAPTER 4 TROUBLESHOOTING IMAGE FAULTS/MALFUNCTIONS
4-31 T
4.1.30 E710
a.E71-0001
Wrong operation, Reader controller PCB
1) Turn off and then on the power switch. Is the problem corrected?
YES: Check the operation once gain; if normal, end the work.
NO: Replace the reader controller PCB.
b.E710-0002
Wrong operation, DC controller PCB
1) Turn off and then on the main power switch. Is the problem cor-
rected?
YES: Check the operation once again; if normal, end the work.
NO: Replace the DC controller PCB.
c.E71-0003
Wrong operation, Main controller PCB
1) Turn off and then on the power switch. Is the problem corrected?
YES: Check the operation once gain; if normal, end the work.
NO: Replace the main controller PCB.
4.1.31 E711
a.E711-0001
Wrong operation
1) Turn off and then on the main power switch. Is the problem cor-
rected?
YES: Check the operation once again; if normal, end the work.
Connector, ADF controller PCB
2) Is the interface cable between the ADF controller PCB and the
reader controller PCB normal?
NO: Correct the cable.
YES: Replace the ADF controller PCB.
b.E711-0002
Wrong operation
1) Turn off and then on the main power switch. Is the problem cor-
rected?
YES: Check the operation once gain; if normal, end the work.
Connector, Finisher controller PCB
2) Is the interface cable between the finisher controller PCB and the
DC controller PCB normal?
NO: Correct the cable.
YES: Replace the finisher controller PCB.
