COPYRIGHT
©
2000 CANON INC
.
2000 2000 2000 2000
CANON iR5000/iR6000 REV
.0 JUL
Y 2000
CHAPTER 6 FIXING SYSTEM
6-38 P
4.6.3
Adjusting the P
osition of the Deliv
er
y Flapper Solenoid (SL5)
Adjust the position of the solenoid using
the scre
w [2] so that the dri
v
e le
v
er [1] is
fully pushed when the solenoid turns on
(i.e., the plunger is drawn).
F06-406-07
[2]
[1]
Download Free Service Manual at http://printer1.blogspot.com
418
420
