3.1.2 Distribution of Power Among Switches
The machine’s power is supplied to each load in conjunction with its respective switch:
Control panel switch ON
Standby
Con-
trol
side
Load
side
Main power switch
(SW1)
Environment switch
(SW3)
Cassette heater
switch (SW4)
Drum heater (H3)
Cassette healer
(H4)/deck heater
(H5)
Lens heater (H6)/
mirror heater (H7)
DC power supply
PCB
Main relay (RL1)
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
ON
Half
wave
ON
ON
OFF
OFF
ON
ON
OFF
Half
wave
OFF
OFF
ON
ON
ON
ON
ON
Half
wave
ON
ON
ON
ON
Control panel switch OFF
ON
ON
OFF
Full
wave
OFF
OFF
ON
ON
ON
ON
ON
Full
wave
ON
ON
ON
ON
Printing
ON
ON
OFF
Half
wave
OFF
OFF
ON
ON
ON
ON
ON
Half
wave*1
OFF
OFF
ON
ON
Power save
ON
ON
OFF
Full
wave
OFF
OFF
ON
ON
ON
ON
ON
Full
wave
ON
ON
ON
ON
*1: If underlined, applies to the 100-V model; the 120/230-V model is subjected to full-
wave control.
T07-301-02
The following are the default settings of the cassette heater switch (SW4) and the environ-
ment switch (SW3):
Default setting 100-V model 120-V model 230-V model
Cassette heater switch (SW4) OFF Not provided OFF
Environment switch (SW3) ON OFF OFF
T07-301-03
