36 MODE
1 ADJUSTMENT
[7] Recall Standard Data (Process
Adjustment)
Restoring process adjustment settings to standard val-
ues (factory setting data).
[8] Tray Adjustment
This adjustment should be performed when the tray or
by-pass unit is replaced.
Step Operation
1
Enter the 36 mode.
2
[Adjustment mode menu Screen]
Press " Process adjustment".
3
[Process adjustment mode menu
Screen]
Select " Recall standard data".
4
[Recall standard data Screen]
Press the key.
Various data is restored to standard val-
ues.
5
Press the key to return to the
Process adjustment Screen.
1
5
YES
RETURN
Step Operation
1
Enter the 36 mode.
2
[Adjustment mode menun Screen]
Press " Image adjustment".
3
[Image adjustment mode menu
Screen]
Select " Tray adjustment".
4
[Tray adjustment Screen]
Press the or key to
select the tray to be adjusted.
The screen changes from Tray 1 to Tray
2 to Tray 3 to By-pass tray 1 to By-pass
tray 2. (7155/7165)
The screen changes from Tray 3 to Tray
4 to By-pass tray 1 to By-pass tray 2.
(7255/7272)
Using a scale, perform each adjustment
individually, set the distance between
(the inner surfaces of) the paper side
guide plates of each tray to 210mm
(A4R) .
Set the distance between (the inner sur-
faces of ) the paper side guide plates of
by-pass tray 1 to 210mm (A4R) and tray
2 to 280mm (8.5
×
11) respectively.Vari-
ous data is restored to standard values.
5
Press the key.
The selected tray is automatically
adjusted.
After adjustment completes, a message
is displayed.
6
Press the key.
2
1
4
NEXT BACK
Start
RETURN
1-56
MODEL MANUAL REVISED EDITION DATE PAGE METHOD
SERVICE MANUAL Dec. 2003
7155/7165/7255/7272
1-56 REPLACEMENT
4
To Next Page
