TIMING CHART
5 ELECTRIC PARTS LIST
[2] 7165 Timing Chart (2)
A4, life size, 1-2 mode, Tray 1, 2 sets
Symbol
Items
Time (sec)
M1 Paper feed motor M2 Drum motor M3 Developing motor M4 Fixing motor M5 Conveyance motor M6 Loop roller motor M7 Paper exit motor M8
Reverse paper exit motor
M9 ADU reverse motor
M11 Scanner motor
MC1 Registration MC MC2 ADU deceleration MC MC3 Paper feed MC/1 MC4 Pre-registration MC/1
PCL Pre-charging exposure lamp
HV
Charge Transfer Separation Developing bias Paper guide plate Toner guide roller
SD1 Separation claw SD SD7 Reverse gate SD
PS1 Paper feed PS/1
PS36 Loop PS PS44 Registration PS PS43 Leading edge PS PS30 Fixing exit PS PS42 Paper reverse PS PS46 Reversed paper exit PS6 PS45 ADU paper reverse PS PS48 ADU paper conveyance PS/2 PS49 ADU deceleration PS PS50 ADU pre-registration PS PS37 Paper exit PS
01234 67895
(sec)
H
L
H
L
F
R H
L
H
L
F F
R R
Stop print
Loop Loop Loop
LoopLoop
Loop
5-49
