SERVICE SCHEDULE
4 SERVICE
4
[10] Periodic replacement parts list
1. Main body
No
Classification Parts name Parts No. Qty Total count Actual count Parts count No.
1 Maintenance
(Every 250,000 copies)
Charging control plate
56AA2503* 1 250,000 6
Charging wire
56AA2509* 1 250,000 22
Charger cleaning base
56AA2540* 1 250,000
Charger slide block
56AA2538* 1 250,000
Charger cleaning block /U
56AA-253* 1 250,000 7
Resin ring (
φ
2) (charging corona)
45AA2040* 1 250,000
Charger cleaning block /L
56AA-254* 1 250,000 8
Toner guide roller (7155/7165)
56AA-213* 1 250,000 5
Toner guide roller (7255/7272)
56QA-213* 1 250,000 5
Cleaning blade
56AA2010* 1 250,000 4
Developer
- 1 250,000 2
Discharge wire
56AA2609* 3 250,000 10
Transfer cleaning assembly
56AA-264* 1 250,000 11
Separation cleaning assembly
56AA-267* 1 250,000 21
Resin ring (
φ
2) (transfer/separation
corona unit)
45AA2040* 2 250,000
Ozone filter K (7155/7165)
55FA7301* 1 250,000 24
Ozone filter/M (7255/7272)
56QA1059* 1 250,000
Ozone filter/S (7255/7272)
56QA1057* 1 250,000
Developing suction filter (7155/7165)
56AA-735* 1 250,000
Developing suction filter (7255/7272)
56QA7320* 1 250,000
Fixing web unit
56AA-543* 1 250,000 1
Fixing claw /U
56AA5427* 6 250,000 14
Transfer presser rubber (7155/7165)
55VA2615* 3 250,000
Transfer presser rubber (7255/7272)
56AA1783* 3 250,000
2 Periodic check (I)
(Every 500,000
copies)
Fixing roller /U (7155/7165)
56AA5305* 1 500,000 12
Fixing roller /U (7255/7272)
56AE5305* 1 500,000 12
Insulating sleeve /U (7155/7255)
45405339* 2 500,000 16
Upper roller bearing
45407504* 2 500,000 17
Fixing roller /L
56AA5306* 1 500,000 13
Fixing claw /L (7155/7165)
25BA5333* 3 500,000 15
Fixing claw /L (7255/7272)
56QA5320* 3 500,000
Fixing rolling bearing
25SA7603* 2 500,000
Decurler roller
56AA5307* 1 500,000
Drum separation claw
56AA2070* 3 500,000 9
Drum
- 1 500,000 3
Paper feed conveyance roller rubber
(Tray 1 to 3)
25SA4096* 3 125,000 30,35,40
Double feed prevention roller rubber
(Tray 1 to 3)
25SA4096* 3 125,000 30,35,40
Paper feed conveyance roller rubber
(by-pass feed)
54004056* 1 70,000 50
Double feed prevention roller rubber
(by-pass feed)
54004056* 1 70,000 50
4
4
4
4
4
MODEL MANUAL REVISED EDITION DATE PAGE METHOD
SERVICE MANUAL Dec. 2003
7155/7165/7255/7272
4-16 REPLACEMENT
4
