MAIN BODY
1-17
1 OUTLINE
[8] Paper Exit Drive Section
[9] Toner Supply Drive Section
Paper exit motor (M7)
Paper exit roller
Exit conveyance roller
Toner cartridge
Toner bottle
motor (M13)
Toner supply screws
Toner supply motor (M12)
Toner supply screw
Toner conveyance screw
[Rear view]
[Front view]
1-11
