Konica Minolta 7155 User Manual

SERVICE SCHEDULE
4 SERVICE
4
[4] RADF [DF-316/DF-322]
1. Periodic check (I) (Every 500,000 copies)
2. Periodic check (II) (Every 1,500,000 copies)
[5] FNS [FS-110] (Old type only)/ [FS-210] (Old type only)
1. Periodic check (II) (Every 2,500,000 copies)
NO Classification Service item
Number
of parts
replaced
Implementation classifica-
tion
Materials/tools
used
Clea-
ning
Inspe-
ction
Lubric
-ation
Replace
-ment
1
Paper feed sec-
tion
(1) Feed roller rubber
13QA4127*
1
z
Actual replacement
count: 200 K feeds
(2) Paper feed roller rubber
13QA4104*
1
z
(3) Double feed prevention roller
rubber 13QA4045*
1
z
NO Classification Service item
Number
of parts
replaced
Implementation classifica-
tion
Materials/tools
used
Clea-
ning
Inspe-
ction
Lubric
-ation
Replace
-ment
1
Paper feed sec-
tion
(1) Double feed prevention roller
13QA4001*
1
z
Actual replacement
count: 600 K feeds
4
NO Classification Service item
Number
of parts
replaced
Implementation classifica-
tion
Materials/tools
used
Clea-
ning
Inspe-
ction
Lubric
-ation
Replace
-ment
1
Drive unit (1) FNS up/down motor
13QE-115*
1
z
Actual replacement
count: 2.5 million
feeds
MODEL MANUAL REVISED EDITION DATE PAGE METHOD
SERVICE MANUAL Dec. 2003
7155/7165/7255/7272
4-13 REPLACEMENT
4
