47 MODE
1 ADJUSTMENT
[2] Adjustment Data Display
Displaying a list of machine adjustment values
(factory-set values and current values).
No adjustment (data value change) can be made
in this mode.
[3] Hard Disk Check
This adjustment is to be performed when check-
ing the total capacity and remaining capacity of
the optional hard disk and when error codes
related to the hard disk occur.
Note1: Once the bad sector check and recov-
ery procedure start, it can not be can-
celed. (The STOP button and mode
change key are ineffective.)
Note2: The hard disk is weak against vibration
and shock. When moving the copy
machine, be sure to remove the hard
disk in advance.
Step Operation
1
Enter the 47 mode.
2
[I/O check Screen]
Enter 94 with numeric keys.
Make sure 94 is displayed in the mes-
sage display field.
3
Press the Start button.
4
[Adjustment data display Screen]
Press the or button to display
a desired adjustment item.
5
Press the key to return to the I/
O check mode screen.
Step Operation
1
Enter the 47 mode.
2
Enter 99 with numeric keys.
3
(1) Checking the total capacity of the
hard disk: Press the P button and
enter 1 with a numeric key. Make
sure 99-01 is displayed in the mes-
sage display field.
(2) Checking the remaining capacity of
the hard disk:
Press the P button and enter 2 with
a numeric key. Make sure 99-02 is
displayed in the message display
field.
(3) Checking and recovering bad sec-
tors on the hard disk:
Press the P button and enter 3 with
a numeric key. Make sure 99-03 is
displayed in the message display
field.
4
Press the START button.
End
5
(1) When the total capacity of the hard
disk is checked:
The total capacity of the hard disk is
displayed after "OUT:" in the mes-
sage display field.
(2) When the remaining capacity of the
hard disk is checked:
The remaining capacity of the hard
disk is displayed after "OUT:" in the
message display field.
(3) When bad sectors on the hard disk
are checked and recovered:
"NOW" is displayed after "OUT:" in
the message display field and bad
sector check and recovery start.
Several minutes later, "OK" is dis-
played in the case of normal termi-
nation, "NG" is displayed in the case
of abnormal termination.
When "NG" is displayed, retry bad
sector check and recovery. If "NG"
is displayed again, replace the hard
disk.
1-86
