MAIN BODY
1-11
1 OUTLINE
[4] Paper Feed/Vertical Conveyance/Tray Up Drive Sections
In the case of the 7155/7165
Feed roller
Paper feed MC (MC3/5/7)
Paper feed roller
Pre-registration MC (MC4/6/8)
Pre-registration roller
Double feed prevention roller
Tray 1/2
Drive belt
Vertical conveyance MC/1 (MC11)
Vertical conveyance roller (upper)
Vertical conveyance MC/2 (MC12)
Vertical conveyance roller (middle)
Paper feed motor (M1)
Up/down plate
Tray up drive motor/1 (M16)
Tray up drive motor/2 (M17)
Tray up drive motor/3 (M18)
1-7
