2. Instance of ISW transfer
Instances of ISW transfer are as described below:
• Writing ROM data newly (Ex. when replacing boards)
• Upgrading
3. Error Code
<Error code table action classification >
(a) Program is not executing normally. Restart
from power ON and re-execute the ISW.
(b) Check the ISW transfer data file.
(c) Check that the communication cable
between input devices (PC or ISW tool) is
properly connected.
(d) There is an error in the flash ROM on the
image control board. Restart from ISW. If
the error persists, the life of the image con-
trol board flash ROM may have expired.
Replace the image control board.
Normal startup display Writing method Condition
Image control Flashing timer LED
No display on the operation
LCD
Writing is enabled with
power turned ON.
The copier does not have the
image control program installed.
Others Error code display 25 mode The copier has the image control
program installed.
Normal startup display Writing method Condition
Image control Normal 25 mode The copier has all the programs
installed.
Others Normal
Error Code Description Action No.
01
There is an error in the command to ISW processing unit.
a
1F
A program error is detected.
a
41
Input data format error.
b
42
Invalid machine name input data.
b
43
Invalid board name input data.
b
81
Input device error such as input timeout.
c
C1
Failed to erase flash ROM. (during ISW to image control board)
d
C2
Failed to write to flash ROM. (during ISW to image control board)
d
C3
ROM checksum error. (during ISW to image control board)
e
C4
Output device error such as output timeout.
f
E1
Failed to erase flash ROM. (during ISW to printer control board and FNS
control board)
g
E2
Failed to write to flash ROM. (during ISW to printer control board and FNS
control board)
g
E3
Communication error between image control board, printer control board,
and FNS control board (during ISW to printer control board and FNS control
board)
h
