3.6 Notes for personnel changing over to "Run MyScreens"
Note
When using HMI Operate in the NCU, note that all file names are saved in lower case letters
on the CF card (com, png, txt).
Note
Make sure that the coding is set to UTF-8 in the editor that you are using when saving the
configuration and language files.
Image files
Image files must be saved in the PNG format (xxx.png).
The data must be saved, e.g. for OEM modifications, under
[System oem directory]
/ico/[Resolution]
For further information, see also Chapter Using display images/graphics (Page 61).
Adapting the configuration file
Check your configuration files regarding the following points:
● Compare the start softkeys with the currently permissible softkeys (see list of start softkeys
in the appendix), and if required, appropriately adapt.
● Rename the integrated image files corresponding to the "Image files" point above.
The data is stored, e.g. for OEM modifications, in the following directory:
[System oem directory]
/proj
[System user directory]
/proj
[System add_on directory]
/proj
Adapting the help files
All help files must be saved in UTF-8. Check your existing files, and resave them accordingly
with a suitable editor.
The HTML files are saved in the following directory, e.g. for English:
[System oem directory]
/hlp/eng
[System user directory]
/hlp/eng
[System add_on directory]
/hlp/eng
Fundamentals
3.6 Notes for personnel changing over to "Run MyScreens"
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 41
